A blisk is an aeroengine module with a rotor disk and numerous blades in a single part. Replacing the conventional assembly of an individual disk and numerous removable blades, blisks have become popular since their introduction in the 1980s. Also known as IBRs, blisks are machined from a solid material.
By employing blisks in the compressors and fans of turbojet engines advances performance and refutes the requirement to accumulate the rotor disk and blades. Important equipment can be fashioned in a single setup on the similar machine tool.
As a result of their intricate shapes, blisk machining needs the usage of multi-axis machine tools and cutting-edge CNC software. These machining requires reliable cutting tools. Since most of the blisk machining contains milling, the superiority of the milling cutters is supreme. Frequently, blisks are formulated from Ti or Ni-alloys, so the milling cutters used required to meet strict productive and fail-safe machining needs.
Various big names of the aerospace sector have developed numerous long-lasting milling cutters that help assure the excellence of blisks and boost user’ productivity. For effective production of blisks, one of the key suppliers offers solid carbide endmills, high-quality coated, and MULTI-MASTER tools.
Mostly, for the production of blisk, premium submicron and ultra-fine carbide substrates, together with nano-layer PVD coating tech and cutting-edge post-coating SUMO TEC treatment, to advance tool impact strength and wear resistance for longer life and improved working features.
Blisk milling starts with coarse slot milling, so the key developers advanced ECK-M solid carbide endmills with a geometry of strengthened cutting edges to competently mill titanium.
If the slot to be milled is narrow and deep, tools offer high-performance features and can be put to use for milling fillet areas.
Milling tools contain of a shank carrying interchangeable solid carbide cutting heads, threaded to let a quick-change connection with the shank. The system decreases setup time and can be organized in numerous ways from standard shanks and heads.
If needed, extensions can be used. Obtainable shank materials comprise of:
- Tungsten carbide with better firmness
- Steel for general-duty applications
- Heavy metal for improved vibration resistance
In some blisk rough-slot milling, for example machining Ni-alloys, a trochoidal tool path is the utmost productive. For this machining technique, Iscar, one of the leading developer advanced solid carbides CHATTERFREE endmills EC-H7. Seven flutes with dissimilar helix angles enable high stock removal rates.
Good surface finish and expectable, long tool life are important in finish-milling blisks. The cutting tool regularly works with overhang, rising stability necessities. For these circumstances, it is recommended by means of solid carbide CHATTERFREE tapered ball nose endmills, considered by diverse helix angles of the endmill flutes.
